35mm Hinge Jig, Aluminum Alloy Hinge Hole Drilling Jig, Quick Punch Cabinet Hardware Jig

Specification: Item Type: Hinge Hole Opener Material: Aluminum Alloy Size: Approx. 35mm / 1.38in Scale of Dial: 3mm, 4mm, 5mm, 6mm Drilling Depth: Approx. 12-13mm Thickness Range: 15mm to 25mm Usage: Widely used for hinge installation, door hinge drilling position, woodworking hole auxiliary tool How to Use: 1. Prepare the machine and accessories. 2. Determine the drilling position and insert the locating pin into the limit hole. 3. Loosen or tighten the nut of the clamp until it securely holds the board. 4. Use a hex wrench to lock the limit ring on the red drill bit. 5. Use the electric drill chuck to open the hinge hole. Then replace the other red drill bit guide locator and drill small holes on both sides of the hinge. 6. Install and secure the hinge in the hole, then tighten the screws to secure the hinge. Package List: 1 x Accurate Locator Body 1 x Drilling Guide Locator 1 x 35mm Hinge Drill 1 x 2mm Drill Bit 1 x Depth Locator Ring 2 x Hex Key 1 x Storage Box

• APPLICABLE BOARDS: Press the handle down, the clamping is fast and stable, and the clamping thickness of the cabinet jig is 12‑25mm, useful and practical
• PACKAGE LIST: Hinge jig kit contain 1 accurate positioner body, 1 drilling guide locator, 1 35mm hinge drill, 1 2mm drill bit, 1 depth poositioning ring
• EXCELLENT ALUMINUM ALLOY MATERIAL: 35mm hinge jig is made of excellent solid aluminum alloy. With accurate manufacturing, accurate positioning, incisive drill, wear resistant, erosion resistant and prevention and other features, a hinge fixture can be used for many years
• ADJUSTABLE DEPTH: This hinge hole drilling jig has multiple position limits that allow you to have 3mm, 4mm, 5mm, or 6mm limits set by using two thumb screws. And this hinge jig does allow for more adjustments on how deep you need the hinge cup. The maximum depth is 15mm
• 66MM END STOP THUMBSCREW DESIGN: This hinge jig positioner has an end stop thumbscrew that is set to 66mm from the center of the hinge hole you drill
