4PRO ATS-63A-4P-v3, 50/60Hz, Automatic Transfer Changeover Switch
4.2 (137 items)
Limited Time Sale$80.40 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 210751773 | Release Date | 2026/04/02 | List Price | $53.60 | Model Number | 210751773 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
DESCRIPTION The ATS-63A changeover switch is designed to transfer loads automatically and manually between main power and reserve power sources in a wide variety of 1-3 phase applications. FEATURES - Design based on 63A automatic circuit breakers; - Motorized or manual switching; - 1-3 phase operation; - High reliability due to stable positions of the changeover mechanism energized during switching process only; - Internal position indication lamps and external lamp outputs; - Built-in mechanical and electrical interlocking; - Automatic / Manual switching modes; - Manual switching 3-position handle. INPUTS AND OUTPUTS - Normal inputs/outputs: R, S, T phases+ Neutral - Reserve inputs/outputs: R, S, T phases+ Neutral - External indication lamp outputs. OPERATION Device monitors normal and reserve source control voltages between input pairs 1 and N. In case if there is the normal input control voltage, the device switches the load circuits to the normal power source inputs. If the normal input control voltage is lost, the device comes to a waiting mode keeping the load circuits connected to the normal power source inputs. In case if there is the reserve source control voltage (while the normal control phase voltage is absent), the device swithes the load circuits to the reserve power source inputs. If the reserve control voltage is lost, the device comes to a waiting mode keeping the load circuits connected to the reserve power source inputs. In case if the normal source control voltage is recovered, the device connects the load circuits to the normal power source inputs. Normal power source inputs always have the priority If the Auto mode switch in the OFF position, you could switch the load circuits between normal, ZERO and reserve power source inputs manually.
- Designed to transfer loads automatically and manually between normal power and reserve power sources with the normal source priority
- Suitable for 230V (1 phase), 230/400V(2-3 phase), 120/208V(3 phase), 120/240V (2 phase) 50/60Hz. source switching
- Automatic / Manual switching modes with an additional load disconnected position.
- External indicator connections
- High reliability due to stable positions of the changeover mechanism energized during switching process only
| UPC | 636601330705 |
|---|---|
| Color | Black |
| Terminal | Through Hole |
| Brand Name | 4PRO |
| Unit Count | 1 Count |
| Item Weight | 1.39 Kilograms |
| Switch Type | Push Button, Motorized |
| Circuit Type | parallel |
| Contact Type | Normally Open |
| Manufacturer | 4PRO |
| Actuator Type | Hinge Lever |
| Material Type | changeover |
| Mounting Type | Panel Mount |
| Connector Type | Wire Leads With Crimp |
| Control Method | Touch |
| Current Rating | 63 Amps |
| Operation Mode | Automatic,Automatically |
| Item Dimensions | 7.87 x 4.13 x 3.94 inches |
| Number of Items | 1 |
| Operating Voltage | 240 Volts |
| Number of Positions | 3 |
| Connectivity Protocol | X-10 |
| International Protection Rating | IP54 |
