AC85v~265v/DC300v Power Meter/Electrical Parameter Tester/watt Panel Meter/Test Driver Efficiency/Voltmeter/Ammeter
4.8 (30 items)
Limited Time Sale$34.20 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 211727603 | Release Date | 2026/04/04 | List Price | $22.80 | Model Number | 211727603 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Work Voltage AC85V~265V ,Power Consumption <2W Operating Frequency 45~65Hz Sampling Rate 2 times /s Display mode 8 0.56 inch digital LED display Over Range Display "HHHH" Dimension 128.0mmx135.0mmx32.0mm[1] Installation Screw installation Operating Temperature 0~50℃ Work Environment Humidity ≤85% RH AC Power Measurement Range 0~2500W Power Resolution 0.01W[2] Power Measurement Accuracy 0.5%FS AC Voltage Measurement Range AC85V~265V Voltage Resolution 0.1V Voltage Measurement Accuracy 0.5%FS AC Current Measurement Range AC0~10A Current Resolution 0.001A Current Measurement Accuracy 0.5%FS Power Factor Measurement Range 0~1.000 Power Factor Resolution 0.001 Power Factor Measurement Accuracy 0.5%FS Frequency Measurement Range 45.0Hz~65.0Hz Frequency Resolution 0.1Hz Frequency Measurement Accuracy 0.5%FS DC Power Measurement Range 0~1000W Power Resolution 0.01W[2] Power Measurement Accuracy 0.5%FS ,DC Voltage Measurement Range DC0~300V Voltage Resolution 0.01V Voltage Measurement Accuracy 0.5%FS DC Current Measurement Range DC0~10A Current Resolution 0.001A Current Measurement Accuracy 0.5%FS Efficiency Measurement Range 0~100% Efficiency Resolution 0.1 Efficiency Measurement Accuracy 0.5%FS Wiring instruction: 1. From the Back of the meter, the left Terminal 1, 2 connect AC85V~265V; Left Terminal 3,4 connect the input of Drive power; 2. From the Back of the meter, the right Terminal 1,2 connect the output of Driver,1 is positive, 2 is negative, Terminal 3,4 connect the Load, 3 is positive, 4 is negative. Wiring must be connected as shown above method, or it may cause damage to the tester.Matters needing attention 1.From the Back of the meter, the left Terminal 3,4 connect the input of the Power Supply, the right Terminals 1,2 connect the output of the Power Supply ,don’t connect the reverse side;
- AC Power Measurement 0~2500W,DC Power Measurement 0~3000W
- AC Voltage Measurement AC85V~265V,DC Voltage Measurement DC0~300V
- AC Current Measurement AC0~10A,DC Current Measurement DC0~10A
- Dimension 128.0mmx135.0mmx32.0mm,Screw installation,Efficiency Measurement 0~100%
| UPC | 714929296825 |
|---|---|
| Model | epm5800-e |
| Brand Name | Zhurui |
| Item Weight | 8.82 Ounces |
| Manufacturer | Shenzhen Zhurui Technology CO.,LTD |
| Power Source | Corded Electric |
| Item Dimensions | 4.17 x 3.39 x 3.54 inches |
| Measurement Type | Ammeter, Voltmeter |
| Upper Temperature Rating | 50 Degrees Celsius |
| Minimum Operating Voltage | 85 Volts (AC) |
