Digital Concrete Strength Test Hammer Rebound Hammer Test with Test Range 10-60MPa Nominal Kinetic Energy 2.207J Built in Large Capacity Memory Can Store 999 Standard Components

CNYST Portable Concrete Rebound Hammer Tester Digital Rebound Hammer with Test Range 10-60MPa Stiffness of Spring 785±30.0N/m Can Store 999 Standard Components Support Voice CountingTechnical Specifications: Nominal kinetic energy:2.207J Stiffness of spring:785±30.0N/m Pointer length:20.0±0.2mm Pointer friction:0.65±0.15N Spherical radius of impact rod:R25±1.0mm Working length of spring striking tension spring:61.5±0.3mm Tensile length of spring striking tension spring:75.0±0.3mm Rated value of steel anvil:80±2 Consistency of detection indication:≤± 1 Operating temperature:-4℃~+40℃ Communication rate:115200bps Display:2.08-inch 256x64(dot matrix)OLED display Power supply:1800mAh,3.7V lithium ion battery Working hours:continuous working≥10 hours Test range:10-60MPaFeatures: real-time measurement point strength estimation, and automatically calculate the measurement area strength and component estimated strength after sampling Small size, modular design, easy to replace the mechanical rebound test hammer Built in large capacity rechargeable lithium ion battery, long service life of the test hammer Built in large capacity memory can store 999 standard components, and a single component can set up 99 measuring areas and 159840 measuring point data at most Support break-point continuous test, and data collection is more convenient and humanized Support voice counting, measurement area conversion and component completion voice reminder Through data line connection and computer data processing software, the test data can be processed quickly and the test report can be issued

• In the actual detection, it should be noted that the bounce frequency of the digital rebound test hammer should not be too fast, and the time interval of the second bounce should not be less than 1 second, so as to avoid the impact on the sampling accuracy caused by the bounce of the sensor tension spring when it has not been completely reset
• Do not place the test hammer near magnets, motors or other equipment that will produce strong magnetic fields, and do not use the test hammer in an environment with strong magnetic fields. Exposure to strong magnetic field may cause abnormal operation of the test hammer or damage the test data stored in the test hammer.
• .Please do not bring the test hammer from high-temperature environment to low-temperature environment or from low-temperature environment to high-temperature environment in a short time, which may cause water vapor condensation on the internal and external surfaces of the test hammer.
• Nominal kinetic energy: 2.207J;Stiffness of spring: 785 ± 30.0N/m;Pointer length: 20.0 ± 0.2mm;Pointer friction: 0.65 ± 0.15N
• Test range: 10-60MPa;Power supply: 1800mAh, 3.7V lithium ion battery;Communication rate: 115200bps;Operating temperature: - 4 ℃ ~ + 40 ℃
• Consistency of detection indication: ≤± 1;Rated value of steel anvil: 80 ± 2
• Built in large capacity memory can store 999 standard components, and a single component can set up 99 measuring areas and 159840 measuring point data at most
