FPV High Resolution Thermal Imager 256 * 192/384 * 288/640 * 512 CVBS Camera For Drone(256x192 CVBS 6.8MM)

640 x 512Specification:- Resolution: 640 x 512- Detector type: vanadium oxide uncooled infrared focal plane detector- Effective frame rate: 60fps- Pixel pitch: 12um- NETD: 40mk- Spectral band: 8 - 14um- Lens parameters: F1.0/9.1mm- FOV (HxV): 9.1mm: 48.3°(H) x 38.6°(V)- Polarity/palette: white heat, black heat, fusion, iron red, fusion- CVBSonly has white heat and black heat- Power supply input: 5V - 20V- Power: 0.65W- Output: CVBS- Analog video: PAL- Product size (without lens): 21mm x 21m- Weight (without lens): 23g- Operating temperature: -40 ~ 80- Storage temperature: -50 ~ 80

• High-Resolution Thermal Imaging: This FPV thermal imager captures clear thermal images with resolutions of 256*192, 384*288, or 640*512, providing detailed temperature distribution visuals for your drone.
• Integrated CVBS Camera: Features a built-in CVBS camera, allowing for combined use of standard visual and thermal imaging to deliver comprehensive situational awareness.
• Compact and Lightweight Design: Engineered with a compact form factor, the device is lightweight and minimizes impact on your drone's flight performance and payload capacity.
• Durable Construction: Built with robust materials to withstand various environmental conditions, ensuring reliable performance during flight operations.
• Easy Installation and Compatibility: Designed for straightforward mounting on various drone models, facilitating quick setup and integration into your existing equipment.
