Meter 8-120V 50A/100A/350A Battery Capacity Tester(TK15 50A)

AmmetersAttention:The min voltage of the battery pack should higher than the min working voltage of the coulometer.Application:,lithium iron phosphate battery ,lead-acid battery and nickel-metal hydride battery, which working voltage is from 8V to 120V.Desciption:Type: Battery testerModel: TK15Operating voltage range: DC8-120VCurrent: 50A/100A/350AOverall Size: 66x40x10mmDisplay area size: 32x23mmExternal normal Sampler Size:23x18x5mmTechnical Parameters:Working power consumption: 8.0mA (Max:10.0mA)Standby power consumption: 0.5mA (Max:0.8mA)Sleep power consumption: 50uA (Max:60uA)Voltage acquisition accuracy: +/-1.0%Current acquisition accuracy: +/-1.0%Using ambient temperature rang: 0-35CBacklight on current: 40mA (Max:50mA)Backlight off current: 30mA (Max: 40mA)Battery capacity setting value: 0.-590AExternal normal sampler working current:30.0A (Max:50A)External big sampler working current:50.0A (Max:100A)Features:1.The empty and full voltage of battery can be adjusted2.The backlight automatic open when using3.Automatic memory function when power down4.Fast response rate5.Low power consumption, automatic wake-upDisplay:1.Residual capacity of battery (Ah or mAh)2.Capacity percentage and totem pole display3.Battery voltage4.Battery current5.Powe output6.Remaining time of charge and discharge
